20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport

Product Categories
ACE Container & Parts Co., Limited
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap 20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport from wholesalers

    Buy cheap 20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport from wholesalers
    • Buy cheap 20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport from wholesalers
    • Buy cheap 20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport from wholesalers
    • Buy cheap 20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport from wholesalers
    • Buy cheap 20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport from wholesalers
    • Buy cheap 20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport from wholesalers

    20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport

    Ask Lasest Price
    Brand Name : ACE
    Certification : CSC
    Price : $50,000.00/pieces 1-1 pieces
    Delivery Time : within 30 days
    • Product Details
    • Company Profile

    20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport

    20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport
    Hot Sale Products
    Specifications
    20ft T75 Tank Container

    Low Cost

    Saving land and sea freight, lower cost when long-term use.

    Convenient and fast

    Fast and Convenient for Loading and unloading, washing. Door to door by land transportation, railway, sea transportation.

    Safety and Eco-Friendly

    No leak or pollute the environment, and No pollute the goods themselves. The safest way to transport chemicals and food internationally recognized.
    20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport
    20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport
    20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport
    20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport
    20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport
    20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport
    20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport
    20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport
    20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport
    Tank Container Parts
    20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport
    20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport
    20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport
    20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport
    Product Datasheet
    20ft ISO LNG Tank Container
    Frame Dimensions (L x W x H)
    6058 x 2438 x 2591 mm
    Nominal Capacity
    19500 litre (±0.75%)
    Maximum Gross Mass
    36000 kgs
    Tare Mass
    8950 kg (± 3%)
    Design Temperature (Frame & Tank)
    -196 °C
    Pressure
    Working
    22.0 bar
    Test
    29.0 bar
    Material
    Tank (Shell & Ends)
    SA-240M / 304
    Frame
    Q345D--GB/T1591
    Type of insulation
    High Vacuum Multi-layer Insulation
    Insulation Material
    Aluminium Foil
    Design Code
    ASME VIII DIV. 1
    Approval
    Lloyds or BV Construction Certificate, IMDG, CFR49, ADR/RID, AAR
    600, CSC, TC, TIR, ISO UIC, US/UK DOT
    Packing & Delivery
    20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport
    About Tianjin ACE
    20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport
    20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport
    20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport
    Certification
    20 Ton Capacity 20ft Long Transport Container ASME Standard UN T75 ISO Cryogenic LNG Tank for Customizable and Transport
    FAQ

    Q:. Are your T75 ISO LNG tank container is brand new?
    Yes, our all tank containers are brand new.


    Q: Can you provide the drawing for confirmation?
    Sure, we'll provide the drawing after order confirmed before production.


    Q: Do you have Small or Large Volume ISO LNG Tank Container?
    Sure, we could do Tank Container form 1000L to 60000L.

    And could produce offshore Tank as per DNV2.7-1 / EN12079 Standard.


    Q: Do you provide OEM Service?
    Yes, we have a first-class team and could design as per your requirement.


    Q: Does your T75 iso tank container meet with international requirement?
    All of our iso tank container will be approval by BV //LR / CCS and meet with below requirement.
    ISO 1496/3
    UN Transport of Dangerous Goods
    UIC International Rail Approval
    TIR International Transport Goods under Custom Seal
    CSC International Convention for Safe Containers
    DOT US Code Federal Regulations CFR49
    DOT UK Carriage of Dangerous Goods
    CTC Canadian Transport Commission (Rail)
    AAR American Association of Railroads
    FRA Federal Rail Association USA
    BAM G.D.R Domestic Approval
    ISO/TC11
