    High Security Shipping Containers Door lock set Silver Forged or Flat Handle with ISO Spare Parts and Accessories

    Ask Lasest Price
    Certification : Mill Certificate
    MOQ : 10 sets
    Price : $14.90/sets 100-199 sets
    Delivery Time : within 30 days
    • Product Details
    • Company Profile

    High Security Shipping Containers Door lock set Silver Forged or Flat Handle with ISO Spare Parts and Accessories

    High Security Shipping Containers Door lock set Silver Forged or Flat Handle with ISO Spare Parts and Accessories
    Hot Sale Products
    Product Description
    High Security Shipping Containers Door lock set Silver Forged or Flat Handle with ISO Spare Parts and Accessories

    Shipping Container Door Handle Gear Lock Parts

    The container door lock parts is designed for shipping container to keep security when transportation in the world. All parts is galvanized, which is protect corrosion from sea, rain and others when shipping and as storage.

    One container contains 4 sets of container door lock parts, the container door can be opened fully when 4 sets of container doors lock opened.

    One set of container door locking system includes all parts for one locking rod, please check below detailed parts list.


    Please contact us for more detailed information.


    High Security Shipping Containers Door lock set Silver Forged or Flat Handle with ISO Spare Parts and Accessories
    High Security Shipping Containers Door lock set Silver Forged or Flat Handle with ISO Spare Parts and Accessories
    High Security Shipping Containers Door lock set Silver Forged or Flat Handle with ISO Spare Parts and Accessories
    High Security Shipping Containers Door lock set Silver Forged or Flat Handle with ISO Spare Parts and Accessories
    High Security Shipping Containers Door lock set Silver Forged or Flat Handle with ISO Spare Parts and Accessories
    High Security Shipping Containers Door lock set Silver Forged or Flat Handle with ISO Spare Parts and Accessories
    Custom Made Length and Weld Service
    High Security Shipping Containers Door lock set Silver Forged or Flat Handle with ISO Spare Parts and Accessories
    High Security Shipping Containers Door lock set Silver Forged or Flat Handle with ISO Spare Parts and Accessories
    Product Datasheet
    Other Container Parts Options:
    Specifications_Container Door Lock
    NO.
    DESCRIPTION
    PART NO.
    MATERIAL
    WEIGHT(KGS)
    1
    CAM L.H
    AL-01
    20MN
    0.64
    2
    CAM L.H
    AL-02
    20MN
    0.64
    3
    KEEPER L.H
    AL-03
    20MN
    0.39
    4
    KEEPER L.H
    AL-04
    20MN
    0.39
    5
    FORGED HANDLE
    AL-05
    20MN
    0.77
    FLAT HANDLE
    AL-051
    SS400
    0.866
    6
    HANDLE HUB
    AL-06
    SS400
    0.15
    7
    FORGED RETAINER CATCH
    AL-07
    SS400
    0.086
    FLAT RETAINER CATCH
    AL-071
    SS400
    0.08
    8
    FORGED RETAINER PLATE
    AL-08
    SS400
    0.224
    FLAT RETAINER PLATE
    AL-081
    SS400
    0.19
    9
    BUSH
    AL-09
    SS400
    0.004
    10
    BEARING BRACKET OUTER LARGE
    AL-10
    SS400
    0.40
    11
    BEARING BRACKET OUTER SMALL
    AL-11
    SS400
    0.127
    12
    SPLIT LARGE BUSH
    AL-12
    ABS
    0.041
    13
    SPLIT SMALL BUSH
    AL-13
    ABS
    0.014
    14
    RIVET
    AL-14
    SS400
    0.018
    15
    ANTI-RACK RING
    AL-15
    SS400
    0.055
    16
    LOCKING ROD
    AL-16
    SS400
    5.80
    Other Parts
    DESCRIPTION
    Dimensions(mm)
    Material









    Door End
    ISO Corner Fitting, 8pcs/set
    178x162x118
    SCW490
    Door Hinge Set
    Blade, Pin, Lug, Bush
    Container Door Locking Device
    Door Gaskets
    1143x2254
    EPDM
    Gasket Retainer
    SUS304
    CSC plate
    0.8x100x200
    SUS304
    Door Panel (3 CORR)
    2.0X943X1957
    CORTEN
    Door Vertical Member Edge SQ.Tube
    3.2x50x100x2260
    CORTEN
    Door Horizontal Member Edge, Channel
    3.0x50x150x1024 or 943
    CORTEN
    Door Sill
    4.5x158x150x2400
    CORTEN
    Door Header Lower
    4.0x112.5x113x137.5x2400
    CORTEN
    Rear Corner Post inner
    12x113x40x2353
    CORTEN
    Rear Corner Post outer
    6.0x70x39x230x2400
    CORTEN


    Front End
    Front End Panel
    2.0x1024x2400
    CORTEN
    Front Corner Post
    6.0x209x225x2400
    CORTEN
    Front Bottom Rail
    4.0X115X154x2400
    CORTEN
    Top End Member SQ.Tube (Horizontal)
    3.0x60x60x2112
    CORTEN
    Roof
    Container Roof Panel (5 CORR)
    2.0x1045x2356
    CORTEN
    Door Header Upper (Extension Plate)
    3.0x388x2400
    CORTEN
    Top End Rail (Extension Plate)
    3.0X397x2400
    CORTEN
    Side
    Container Side Panel
    1.6x1116x2400
    CORTEN
    Top Side Rail, SQ. Tube
    3.0x60x60x5702
    CORTEN
    Ventilator Cover
    204x67x25
    ABS





    Base
    Container Plywood Flooring, 19ply
    28x1160x2400
    Hardwood
    Floor screw
    L=5 to 120
    CORTEN
    Bottom Side Rail
    4.5x50x162x30x5702
    CORTEN
    Cross Member Small
    4x45x122x45x2350
    CORTEN
    Cross Member Large
    4x45x122x75x2350
    CORTEN
    Fork Pocket Bottom Plate
    360x300
    CORTEN
    Fork Pocket Top Plate
    360x2350
    CORTEN
    Gooseneck parts
    CORTEN




    Other
    Lashing Ring
    SS41
    Hexagon Set screws Nuts and Bolts
    L=6 to 200
    CORTEN
    Sealed pop rivet Blind rivet
    4.8*16.5
    CORTEN
    Decals: Weight& Capacity, UIC, Container Type, Ower's Serious
    CORTEN
    Open Top Container: Header Hinge,Tarpaulin, Eyelet,TIR Cable, D-Ring
    Flat Rack: Twistlocks
    Packing & Shipment
    High Security Shipping Containers Door lock set Silver Forged or Flat Handle with ISO Spare Parts and Accessories
    Our Company
    High Security Shipping Containers Door lock set Silver Forged or Flat Handle with ISO Spare Parts and Accessories
    High Security Shipping Containers Door lock set Silver Forged or Flat Handle with ISO Spare Parts and Accessories

    ACE Container & Parts Co., Limited has exported products to over 85 countries untill to 2018 year.


    The main export countries include United States, Canada, Australia, Japan, New Zealand, Malaysia, Korea, India, South Africa, Germany, Spain, Netherlands, the United Arab Emirates, etc. With professional product knowledge and many years of export experience, won a good reputation all ove the world.
